API 6A Oilfield Wellhead Adjustable Throttle Choke Valve
Product Introduction
Choke valve is a main component of Christmas tree, is design to control production rate of the oil well, with working pressure up to 15000psi. Choke valves can be classified as follows: adjustable choke valves and positive choke valves. By rotating hand wheel to move the stem, the adjustable choke valve is designed to adjust the effective area available for the flow to accomplish control of production rate. The positive choke valve is design to accomplish control of production rate by changing flow beans.choke valves are supplied in two types: Positive and Adjustable. It's designed as per API 6A, API 16C, NACE MR0175, the structure Type: needle, barrel, cage, orifice and wedge.
Adjustable and positive choke valves are designed for reliable flow control and maximum wear life, The choke valves are available in flanged or threaded ends in standard bore sizes form 1-13/16" thru 13-5/8",in working pressures of 2000 psi through 20000 psi.
Adjustable choke valve:
- Valve needle and spool are made of tungsten carbide,with sufficient corrosion resistant,antieroding and wearable capacity.
- The two kinds of adjustable choke ,needle type and external sleeeve type could apply to wellheads & X-mas tree and choke manifold.
Positive choke valve
- Material of choke bean is fabricated from ceramic and tungsten carbide,with sufficient corrosion resistant,anti-eroding and wearable capability.
- It adopts union bonnet so as to change choke quickly.
- It has application in wellhead & X-mas tree and choke line.
Technical Specifications of Oilfield Choke Valve
| Product name | Chock Valve |
| Working pressure | 2000-20000 PSI |
| Nominal bore | 1 13/16"~7 1/16" (46mm~180mm) |
| Working medium | oil,natural gas,mud and gas containing H2S,CO2 |
| Working temperature | -46℃—121℃ |
| Specification level | PSL 1- PSL4 |
| Performance requirement | PR 1-2 |
| Material class | AA,BB,CC,DD,EE,FF,HH |
| Manufacture standard | API Spec 6A |
| Item | Component | Qty | Material | Remark |
| 1 | Body | 1 | 4130 | |
| 2 | O-Ring | 2 | NBR | |
| 3 | Seat Bushing | 1 | 4130 | |
| 4 | Lower Diversion Bushing | 1 | 410 | |
| 5 | Upper Diversion Bushing | 1 | 410 | |
| 6 | Valve Core | 1 | YG8 | |
| 7 | O-Ring | 1 | NBR | |
| 8 | Bonnet | 1 | 4130 | |
| 9 | O-Ring | 2 | NBR | |
| 11 | Bonnet Stud | 8 | 4130 | |
| 12 | Bonnet Nut | 8 | 5140 | |
| 13 | Stem | 1 | 410 | |
| 25 | Cylinder Adapter | 1 | 4130 | |
| 26 | Cylinder | 1 | | |
| 27 | O-Ring | 2 | NBR | |
| 28 | Piston | 1 | 1045 | |
| 29 | Screw | 1 | 4130 | |
| 30 | Cylinder Lid | 1 | 4130 | |
| 31 | Circlip | 1 | 1566 | |
| 32 | Straight pipe | | | |
| 33 | Washer | 1 | 4130 | |
| 34 | Cylinder Adapter | 1 | 4130 | |
| 35 | Screw | 4 | 4130 | |
| 36 | Seat | 1 | YG8 | |
