API Water Well Drilling Power Swivel for Drilling Rig
Product Overview
Power swivel is a drilling equipment used at trial repair, with a hydraulic motor driving it to rotate. At trial repair, it drives drilling tools to rotate instead of rotary table. The product has been widely used for sand wash-over, drilling out and shallow oil gas drilling and coal gas drilling.
Power Swivel is the device installing on the of servicing rig, to provide rotating power. Except the use for such workover jobs as casing milling, milling, drilling cement plug and bridge plug and fishing, it is also used for sidetracking drilling, drilling open hole and coring. The product is designed and manufactured according to API 8C specifications.
Swivels are divided into two categories: ordinary Swivels and dual-use Swivels. The dual-use Swivels combine ordinary Swivels and spinners into one.
Specialities of Our Oilfield Swivel
- Optional 3LP and 4LP inner and outer spiral water hose joint threads.
- Low temperature resistant Swivels for use in alpine regions can also be provided according to customer requirements.
- Ordinary Swivels are mainly composed of lifting ring, gooseneck tube, packing device, shell, central tube main bearing and joints. The lower joint is connected to the kelly rod through the standard thread, and the upper lifting ring is hooked. The neck tube and the hose can be connected by a standard threaded joint union as required.
- The flushing pipe packing assembly adopts a box structure, which can be quickly replaced on the drill floor without removing the hose and gooseneck.
- The Swive lcomplies with the American Petroleum Institute APLSpec 8c PSL1 product specification.
Main Specifications of Our Oilfield Swivel
| MODEL | SL70 | SL110 | SL135 | SL160 | SL225 | XSL225 | XSL450 |
| Max. static load (Ibf) | 151740 | 25290 | 303492 | 35969 | 505820 | 505820 | 1011640 |
| Working load of main bearing (Ibf) | 67440 | 101164 | 224808 | 269770 | 337213 | 377213 | 562022 |
| Gooseneck pipe thread | 2 3/8" TBG | 4 1/2" NPT | 4 1/2" TBG | 4 1/2" TBG | 4 1/2" TBG | 4" NPT | 4"NPT |
| Bottom thread of central pipe joint | 2 7/8" UP DP | 4 1/2" REG LH | 5 1/2" REG LH | 5 1/2" REG LH | 6 5/8 REG LH | 6 5/8 REG LH | 6 5/8"REG LH |
| Max. working pressure (psi) | 2143 | 3000 | 5000 | 5000 | 5000 | 5000 | 5000 |
| Opening diameter of central pipe (in) | 1.96 | 2.5 | 2.99 | 2.99 | 2.99 | 2.99 | 2.99 |
| Overall dimension (ft) | 5.57×1.49×0.98 | 5.53×0.93×1.67 | 7.41×2.21×2.44 | 7.87×2.33×2.47 | 8.53×2.56×2.60 | 9.45x3.37x3.49 | 9.89×3.59×3.49 |
| Mass (Ib) | 606 | 741 | 1711 | 2176 | 2925 | 5666 | 6746 |
Xi'an TianRui Petroleum Machinery Equipment Company Limited was established in 2010 and located in Xi'an city, China. We have the specialized technicians, senior engineers and professional marketing team. The company is committed to develop, manufacture and supply a variety array of oilfield equipments. The main products include : Petroleum equipments & tools such as drilling equipments, production equipments, tubular goods, wellhead equipments, downhole equipments, well control equipments, cementing tools etc, Petrochemicals.
With “Professional & Efficient, Customer Focus, Win-win Cooperation” as the operation principle, we believe that we will become your best cooperative partner in China.
Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
